DB-51/62 BOPS Fully Automatic Plastic Thermoforming Machine
Model | DB-51/62 |
Max.Forming Area | 510x620mm |
Max.Forming Depth | 100mm |
Knife Length | APET：6000mm/ PVCPLA：7000mm/ OPS：10000mm |
Material Thickness Range | 0.10-1.0mm |
Air Pressure | 0.7Mpa |
Air Consumption | 2200 Litres/min |
Water Consumption | 10 Litres/min |
Power Consumption | 7.5kw/h(Approximate) |
Total Heating power | 24kw |
Total Motor power | 8kw |
Power Supply | AC380V±15V 50/60HZ |
Production speed | 600-1500 Cycles/h |
Dimensions | 2750x1460x2350mm |
Weight | 2500kg |
